LINE PROFILERS

AUTOMATE. INSPECT. OPTIMIZE.

EMPOWER YOUR FACTORY WITH SMART 3D

Gocator G1 family logo 0 1 0

3D LASER LINE PROFILE SENSORS

For All Your Inline Inspection and Optimization Needs

Gocator line profile sensors use a projected laser line to perform high-resolution scanning, measurement and control for automated quality inspection and material optimization at inline production speed.

FIND THE RIGHT 3D LINE PROFILER FOR YOUR APPLICATION

G2100 series intro

Gocator 2100 Series

Entry-Level 3D Line Profilers

  • Handles all of your basic quality inspection needs
  • VGA imager, 640 points per profile resolution
  • Field-of-view up to 1260 mm
  • Measurement range up to 800 mm

Gocator 2300 Series

Workhorse 3D Line Profilers

  • Handles a wide range of high-speed, high-volume applications
  • Megapixel imager, 1280 points per profile resolution
  • Field-of-view up to 1260 mm
  • Measurement range up to 800 mm
G2300 Series Intro 2 0
24XX Family Fanned

Gocator 2400 Series

High-Resolution 3D Line Profilers

  • Handles targets from small electronics parts to large boxes and automotive body frames
  • 2-Megapixel imager. Up to 1940 points per profile resolution
  • Field-of-view (FOV) up to 2 m
  • Measurement range up to 1525 mm
  • Includes RED LASER and BLUE LASER models for optimal performance and maximum flexibility in your scanning applications

Gocator 2500 Series

High-Speed 3D Line Profilers

  • Handles small-medium parts inspection on a wide range of surface types (e.g., shiny, dark)
  • 2-Megapixel imager. Up to 1920 points per profile resolution
  • Scan, measurement, and control at up to 10 kHz
  • Field-of-view (FOV) up to 518 mm
  • Measurement range up to 595 mm
G25X0 isoL new
Gocator 2600 Series Remastered

Gocator 2600 Series. Remastered.

4K+ Resolution and Wide Field of View 3D Line Profilers

  • Handles microscopic features and large conveyor applications
  • 9-Megapixel imager. Up to 4192 points per profile resolution
  • X-Resolutions up to 2.5 microns
  • Scan, measurement, and control at up to 10 kHz
  • Field-of-view (FOV) up to 2 m
  • Measurement range up to 1550 mm

Gocator 2800 Series

Dual Triangulation 3D Line Profilers

  • Two cameras maximize scan coverage and minimize occlusions for
    applications such as primary log scanning
  • Megapixel imager, 1280 points per profile resolution
  • Field-of-view up to 1260 mm
  • Measurement range up to 800 mm
G2800 series Intro 1

Find Your Sensor

Need some help finding the right Gocator® for your application? No problem.

Simply visit our dedicated Product Selector, enter a few details about your application, and the Selector will automatically generate a list of suitable sensor models for you to choose from.
