Increased Speed. Higher Resolution. Enhanced Data Quality.
The remastered Gocator 2600 Series has been optimized for faster default scan speeds, enhanced data quality, increased scanning versatility, and higher 4K+ resolutions.
Cell Phone Black Glue Inspection
NEW! Gocator® 2610 4K+ laser profiler
EV Battery Pre-Weld Seam Gap & Flush Measurement
NEW! Gocator® 2618 4K+ laser profiler
Cell Phone ASF Adhesive Tape Detection
NEW! Gocator® 2629 4K+ laser profiler
Gocator® 2600 Series. Remastered.
Optimized for Speed, Resolution, and Data Quality
- 9-MEGAPIXEL IMAGER
- UP TO 4192 POINTS PER PROFILE FOR HIGH-RESOLUTION 3D MEASUREMENT AND INSPECTION
- X RESOLUTIONS UP TO 2.5 MICRONS
- Z REPEATABILITY UP TO 0.2 MICRONS
- FIELDS OF VIEW UP TO 2 M (AT 0.55 MILLIMETER X-RESOLUTION)
- ON-SENSOR MEASUREMENT TOOLS AND I/O CONNECTIVITY
- ONBOARD MULTI-SENSOR ALIGNMENT AND NETWORKING SUPPORT
FINE-TUNED FOR EVEN MORE POWERFUL 3D MEASUREMENT AND INSPECTION.
Higher 4K+ Resolution ModelsFOR MEASUREMENT AND INSPECTION OF ULTRA-FINE FEATURES
The new Gocator 2610 model generates profile and surface data at up to 2.5 microns X resolution for inline dimensional measurement and microscopic surface defect detection on small parts such as semiconductor Ball Grid Arrays (BGAs). The new Gocator 2618 model achieves 5 micron X resolution at 20 millimeters field of view for specialized EV Battery applications such as pre-weld seam gap & flush measurement.
Faster Default Scan SpeedFOR OUT-OF-THE-BOX DEPLOYMENT INTO HIGH SPEED APPLICATIONS
The Gocator 2600 Series has been optimized to provide higher default scan speeds. Existing job files will retain their original configuration and scan speeds.
New HDR ModeFOR IMPROVED DATA QUALITY ON HIGHLY REFLECTIVE AND OTHER CHALLENGING SURFACES
The new High Dynamic Range (HDR) Mode improves scan quality on challenging targets that previously were susceptible to over or underexposed features (e.g. highly reflective metallic surfaces and objects with a variety of materials and finishes). Targets that previously required multiple exposures to scan challenging features may now be captured with a single exposure and faster cycle time.
Optimized Surface FlatnessFOR IMPROVED ACCURACY IN INSPECTION OF A VARIETY OF SURFACES
The Gocator 2600 Series has been optimized for surface flatness with a pre-processing pipeline to reduce spatial noise. This allows users to more accurately locate, measure, and identify features on a variety of targets and applications. The new Gocator 2629 model delivers optimal speed and data quality over a large (>70 mm) field of view. Scan larger CE targets in a single pass with a single sensor, with sufficient optical performance for challenging inspection requirements such as verifying placement of thin adhesives.
Explore Blue Laser Profiling for EV Battery Inspection
Find out more about applications using Gocator blue laser profilers for 3D scanning and inspection in EV battery manufacturing.
LET’S TALK ABOUT THE BENEFITS OF OPTIMIZED 4K+ LASER LINE PROFILING FOR YOUR PRODUCTION LINE.
Discover the power of optimized laser-based measurement inspection for a wide variety of manufactured assemblies and materials.
